MABER MBC2000

Goods and Passenger Hoist

MBC2000-image-2


Features & benefits

The MABER MBC 2000 heavy-duty goods/passenger hoist is capable of reaching heights of 150 meters with a lifting capacity of 2000kg. A single-mast dual-purpose hoist that has an additional overhead protection piece that can accommodate 7 passengers in transport platform mode. The platform size of 3.2m x 1.5m ensures ease of use for loading pallets of plasterboard and offers a fully opening bi-fold C gate.

2000kg SWL / 7 persons.
415v power supply.
Up to 150m high.
Lifting speed personnel 12 m/min.
Lifting speed goods only 24 m/min.
Large 3.2m x 1.5m platform with 3 entry-exit points.
Different ramp configurations are available to suit site needs.

MBC2000-image-1

At the base

MBC2000-image-2


Loading at the base

MBC2000-image-3

Hoist at the landing position

Technical data

Download Spec Sheet

Maximum Height

Lifting Capacity - Goods Mode

Lifting Capacity - Personnel Mode

Lifting Speed - Goods Mode

Lifting Speed - Personnel Mode

Power Source

Breaker Rating

Power Requirements

Start up Current (Max)

Running Current (Max)

Cage Dimensions (Internal)

Approx. Ground Space Required

Approx. Minimum Access Required

Approx. Gate Opening Dimensions

Maber MBC2000

150m

2000kg

7 persons

24 m/min

12 m/min

415v Electric

63a Three Phase C Type MCB

Dedicated 415v 63a Commando Socket

203a

38a

W 1500mm - L 3200mm

3800mm x 4600mm

Contact us

2000mm +
